ERC721 Token Implementation: Solidity Smart Contract and OpenSea Integration

[00:00:00]Welcome back to day two of my journey to  develop my first-ever crypto collectible   and smart contract for the Ethereum blockchain.  If you haven't watched the first video I highly   recommend it. Today we will write our first  smart contract in solidity and figure out   how we can connect our own NFT  to marketplaces like OpenSea.   If this sounds like a lot of work  you're right it was a hell of a day.

[00:00:33]So here is the idea: I want to develop  a non-fungible token called Date Token,   so you can mint your own token for every date  in our calendar. From year one till now. Unless   somebody else already owns that token. Every Date  Token is unique. You could mint your birthday,   or the date of the moon landing or the  invention of the light bulb, whatever   date you want to own. And I want to store all the  needed information inside of the blockchain: year,   month, and date. That sounds like a small and  achievable goal for one day let's see how it goes.

[00:01:07]Some of you might ask: What is an NFT?  NFT stands for non-fungible token. A   token is something you can have inside  of your wallet. If you have one ether,   that would be one token of ether inside of your  wallet. But what does non-fungible mean? Fungible   means replaceable by another identical item  and non-fungible means basically the opposite.   So if I give you a dollar and you give me one  of your dollars we both end up again with one   dollar. There is no value difference in your  dollar to my dollar. Dollars are fungible.

[00:01:35]But if we were to trade Pokemon cards. I give  you one of my Pokemon cards and you give me   another one of yours. We both have the same  amount of pokemon cards after the exchange,   but the value of the two cards is not necessarily  the same. Pokemon cards are non-fungible.

[00:01:49]The same goes for the Date Token. If  I owned the date of the moon landing   and you own some other random date, I  certainly don't want to trade with you,   because the intrinsic value of my  date might be higher than yours.

[00:01:59]I learned that there are different tokens on the  Ethereum network and each token needs a certain   smart contract to be implemented in order to work.  If you want to create your own currency you would   need to implement the ERC20 token and for NFTs  you use ERC721. ERC20 and ERC2721 are basically   interfaces you need to implement in your smart  contract in order to be recognized as a currency   or an NFT on the Ethereum network and so that  other dApps can identify and use your tokens.

[00:02:34]If you have looked into NFTs before, you  certainly found the website OpenSea. OpenSea is   a marketplace. On there you can buy and sell your  NFTs. All of these are so-called ERC721 tokens.

[00:02:45]You can also create your own NFTs here on OpenSea.  You just need to upload whatever graphic, video,   or audio file you want and OpenSea creates an  OpenSea NFT for it. What OpenSea basically does,   is creating an OpenSea token, which is connected  to your media file using their own smart contract.

[00:03:00]But doing that would be way too easy. We want  to create our own smart contract. In order to   create our own ERC721 smart contract, we could  write implementations for all of these functions.   Or we could use OpenZeppelin: A library  for implementing different types of ERC   tokens. OpenZeppelin can be installed using  NPM and helps us by implementing almost   all of the functionality we need for our  ERC721 token. We just need to fill in the gaps.

[00:03:26]So I installed OpenZeppelin using NPM and built my   first ERC721 smart contract.  This is what we got so far.

[00:03:34]I created a file "date.sol". I added  a little header. I imported the   OpenZeppelin ERC721 contract and the contract  date is ERC721. I call the constructor,   define my own token name, and my own token  symbol. I inherit all the functionality I need.

[00:03:52]And, yeah, let's try to  compile it. "truffle compile".

[00:03:57]So the next step is to actually migrate  our smart contract to our local ganache   blockchain. As far as I know, I  need to write "truffle migrate".

[00:04:07]Okay, it went through. In ganache, there's a tab  called "contracts". Going there I see a Migrations   and I see a Date contract, but it is not deployed,   which means we have to add our Date  contract to our migration script.

[00:04:22]For that to work, we need a new file in  our migrations subfolder starting with a   2, so it's the second migration step. I call that   "2_token_migration.js". In there i need to load  my smart contract and deploy it to the blockchain.

[00:04:39]So what's basically happening here is,  that we import our "date.sol" file somehow   and we export a function that calls the  deployer to deploy our data. Let's try it out… And this time you see, that a  second migration phase is executed:   "2_token_migration.js", "Deploying Date" So if I open up ganache now  I see that our contract Date   is actually deployed and has the  following address. That worked … After this first success, All I need to do is to  implement the rest. I want to store the year month   and day on the blockchain, I also want that  the user can add a title to each date, and   I have this idea of different materials to make  minting more exciting, but more on that later.

[00:05:21]The development cycle for smart  contracts basically works like this:   You implement a function. To make sure it  works, you implement a Unit Test for it.   truffle.js comes with a testing framework  so you can make sure your smart contract   works before you deploy it locally to  a test net or finally to the main net.

[00:05:37]It has been a couple of hours now and I  think I have the Date token smart contract   ready. So here's what I got so far … I want to store the year, the month, the day, a  title for the date token, and the color on the   blockchain. So what I did is to define this struct  metadata. I added this mapping here, where I map   the token-id to the metadata. This is basically  how you store data inside of the blockchain.

[00:06:01]The constructor is executed when you deploy  your smart contract to the blockchain   and because I want to have  some Date tokens for myself,   I call this mint function nine times to generate  some interesting Date tokens for my wallet.

[00:06:14]The mint function takes a year, month, day,  and a color, as well as a title to create a   new token. It's defined "internal" so only the  contract itself can call it and nobody else can.

[00:06:27]In order to create a token for  yourself through the web app,   I have a different endpoint  defined which is "claim".

[00:06:34]It has the same parameters, not the color because  the color is randomly chosen, it's external so   everybody else can call it, and it's  payable so you have to pay a little fee   in order to create your own Date token.

[00:06:46]It costs 10 Finneys to create a Date token. So if  that is not given you get a little error message.   And then we check the incoming parameters  for validity. If they are valid, I generate a   different color based on some probabilities I have  chosen. Put it into the mint function and transfer   the 10 Finneys that you have to pay to my account  because I am the owner of the smart contract.

[00:07:11]I can "get" a Date token: So I  want to read the metadata that   is associated to a token-id. So  that's the "get" function here.

[00:07:19]I can get the title of the Date token.  Either by token-id or by year, month, day.

[00:07:25]I can change the title of the Date token. But  only, If the token exists and, down here, if   the owner of the Date token is calling this  endpoint. If you don't own a Date token,   you can't change the title.  If you own it, you can.

[00:07:39]One cool thing is that truffle.js comes bundled  with a testing framework. The first thing we   test is if, after deployment of the date token,  the owner of the Date contract is correct. In   the test environment, the first account in the  ganache blockchain is deploying the contract.   So we check if the deployed contract  date has the correct owner. Like this.

[00:08:02]We check if the name is correct, if the token  symbol is correct, we check for the base URI   or the token URI. Then we check if I as  the owner get all the Date tokens that   I have defined in the constructor.  And then I check that minting a date   actually works and that you have to pay  the 10 Finneys to get the date token.

[00:08:20]I know that I went over this code  rather quickly, but remember the   link to all the code is down in the description  below if you want to have a closer look.

[00:08:27]Now, let's try to run the  tests, compile the contract, and   migrate it to the ganache blockchain.

[00:08:35]"truffle test" runs the test suite. All the tests   went through successfully. Let's  compile the contract: "truffle compile" "truffle migrate" to migrate the contract  to the blockchain, but since we already have   migrated the contract to the blockchain  once, we need to add "--reset" to the   command line parameters so we reset the  blockchain and can redeploy our contract.

[00:09:01]Bringing up ganache now, I see  that the contract is deployed   and that I paid a little bit  of gas for the deployment.

[00:09:07]Looking at MetaMask, we see that MetaMask is not  showing the nine Date tokens, that we should have   because of the deployment of our smart  contract. But we can add the token… Go to "custom token" and  paste the contract address   here. It automatically reads the token  symbol. We go "next" and see nine Date tokens.   So now in our MetaMask wallet, we see the  nine Date tokens, that we own. Amazing!

[00:09:34]If you remember OpenSea and all the little  images on it, you might ask yourself:   "how does OpenSea know what  to show for each token?"

[00:09:42]Looking at the OpenSea developer documentation,   you see that each ERC721 token has something  called a "tokenUri". In there you can store   any kind of URI and OpenSea reads this to  get its needed information. It basically   expects a JSON like the following. In here the  title and description of the token is defined,   as well as a link to an image, and some  optional arbitrary attributes. So what we   need to do is to implement a service which  returns the JSON for each of our tokens.

[00:10:10]After I found out about this, I  spent the last couple of hours   thinking about a nice representation for  our Date tokens so they look good inside   our collection on OpenSea.  Here is what I came up with… The Date token should be represented by this  futuristic-looking card. On there we have the date   written out, as well as the token-id and a barcode  encoding all the information of this token. The   top half consists of three parts. We have five  squares in the center which encode the day of   the month. So it looks different for Elon Musk's  birthday or the moon landing or the start of the   Ethereum blockchain. It is a 5-bit encoding  of the numbers 1-31. The triangles represent   the month. So January looks different than June or  December. 4 bits for 12 months. And the last part,   the dots on the circle, represent the year.  Which again is simply a binary encoding.

[00:11:08]OpenSea supports animated SVGs. So, of course, I  want it to be animated. And because I want to have   some rarity factor for each minted date token, I  also invented eight different colors: blue, green,   red, black, silver, gold, neon, and pearl which  get chosen randomly during the minting process.

[00:11:32]Now, let's program a  javascript express.js service,   which generates those SVGs and  the JSON needed for OpenSea.

[00:11:43]So how did I do it: I implemented an express.js  server app. I used web3.js to connect to our   ganache blockchain like this. After that, I got  all the contact information from our compiled   JavaScript ABIs that truffle generates  in order to interact with the contract   and handing in the contract address from our  migrated contract. This way I can actually call   the functions inside of our smart contract. Then  I have one endpoint for OpenSea to get the JSON,   and another endpoint for  OpenSea to get the SVG image.

[00:12:20]Inside of the first endpoint, I call  a contract method "get". You remember   "get" is the contract method that returns the  metadata that we store inside of the blockchain:   year, month, day, color, and title. And  I use this information to generate the   JSON for OpenSea and to put in the URL to our  SVG endpoint to get the right representation.

[00:12:42]And down here we generate the SVG. All of the  code generating the SVG is inside the "svg.js"   file that I put into the repository  as well. So if you want to look at it,   there's a link in the description below.

[00:12:57]And that's it for today good night.

[00:13:00]Day two is a wrap. And what a day it was!

[00:13:04]If you want to follow my journey  consider subscribing. Thanks to   my patrons for helping running  this channel. I see you in one   of my other videos if you want. And  as always have a lot of fun coders!
