Soft Body Physics in Games: From Particles to Simulation

[00:00:00][Music] Today we're going to teach our AI how  to do absolutely nothing because this isn't about reinforcement learning it's about this.  Have you ever wondered why games aren't filled to the brim with soft things? Like where is the  jelly, the bouncy ball, the noodle, the cloth, the inflatable Barry? Well the answer to this is  pretty straightforward; soft bodies, ironically, are pretty hard. Programming them is anything but  straightforward. You see, working with physics engines is the opposite of working with with  people; the stubborn, hard objects are easy to work with. They are unbending unbreaking and rigid  you know exactly where they're supposed to be, whereas these soft pliable things are always  changing their minds, so you have no clue what they're supposed to be doing. What I'm trying to  say is it could be pretty overwhelming to try and go from rigid bodies to soft bodies in one motion  so let's start small. This is a particle let's call it Shane there isn't really anything special  about this particle it's simply just a hard ball, a rigid body, something that's been implemented  into nearly every game in existence. Now Shane here has a friend let's call them Natasha.  Shane and Natasha share a special bond; if they get too close they will push away from each  other, if they get too far they will pull back together which sounds like a toxic relationship  but I think that's pretty healthy. You can think of this as a force that is proportional to the  distance they are from their preferred position.

[00:01:30]This is also known as the Spring Force Formula  or Hooke's Law. We could also add some stability by applying a force that directly opposes any  motion between these two particles. This is commonly referred to as dampening. Together, these  two forces create something called a Mass Spring Damper Model most games just call this a Spring  Joint for simplicity though. We can take this idea and extend it to include a whole family of  particles. We can treat these eight particles like corners of a cube and give them each three spring  joints which connect them to their neighbors.

[00:02:03]This structure already gives us promising  results but there are a few glaring issues, the most obvious one being that this structure  is completely hollow. It's basically a ghost unless you happen to touch the corners. But this  isn't really that much of an issue, because we can take this concept even further by creating a  whole grid of particles that are each connected to their neighbors. There are still gaps in the  structure, but they are much smaller. Remember, when it comes to making games there is Mr quality  and then there Miss's performance and you have to keep them both happy. Right now you might be  thinking is that it? and yeah, that's all there is to it, this is a fully functional soft cube!  It turns out it actually wasn't tha- a I spoke too soon. You didn't really think it was going to be  that easy did ya, hahaha. So what went wrong here?

[00:02:49]Why did the whole thing just collapse on itself  like a house of cards? This phenomenon is known as shearing, but what is shearing? Shearing is  the process by which the wooden fleece of a sheep is cut off the person who removes th- wait what  am I reading right now? Shearing is essentially when two surfaces slide in opposite directions to  each other, which is bad in this case, because the spring joints don't really care if the structure  collapses because each spring can maintain the distance at wants in many configurations. The best  way to fix this is to add diagonal spring joints.

[00:03:20]Naturally, these new springs will be longer than  the original ones which means they any movement away from the original shape of the soft body  will be opposed, which will keep it together.

[00:03:29]This improved structure already looks incredibly  good and gives us some nice floppy action down the staircase. We can also play with the strength and  dampening of the spring joints within to create different characteristics depending on what we  want. We aren't just limited to a cube either, we can resize the grid to any dimension we  like and the structure will still work... like what happens if you shrink a cube down to  two dimensions? That's right you get a towel.

[00:03:52]Now this is some pretty cool stuff but you may  have noticed one of the other issues I alluded to before these objects look a little...  naked. It kind of looks like someone got way too excited about Lisa's pearl necklace  and started creating questionable fan-art.

[00:04:07]We need a way to dress these structures up  and that starts with a mesh. If you don't know what a mesh, is it's basically  just a bunch of points, or vertices, that form triangles that form a solid 3D structure  or at least they should but sometimes people are bad at modeling. One way we could use a mesh is  to wrap it around an existing soft body structure, but we can do way better than that. Instead  we are going to use the mesh as a reference to generate the perfect soft body structure  inside. It there are many ways to do this, but for the sake of simplicity I'm going to use a  fairly straightforward and naive approach. First, we will take every unique vertex and promote it to  a particle. It's important to only use the unique ones as we don't want to create two particles  that are occupying the same spot. Meshes can be pretty complicated, and there are cases where  having duplicated vertices actually make sense.

[00:04:58]Once these particles alive their corresponding  vertices will move with them, synchronizing the mesh's shape with the movement of the particles.  Once this is done we will scan through the mesh and create particles on the inside this is done by  creating a 3D grid around it and iterating through each potential spot to see if it's inside  the mesh. Now when I say 'inside the mesh' it implies 'collision detection with meshes'  which implies pain and suffering for even the most experienced programmers. For me, my pain and  suffering occurred in 2020 when I decided to make a game that completely relied on meshed collisions  or more specifically, a binary tree for triangles.

[00:05:35]Binary trees are essentially a way of recursively  splitting a set of data in half. For instance, let's take the number 5. 5 is an interesting  number because it's more than twice the size of two and roughly half the size of 11 now let's add  2 and 11 to this. The rules of binary tree state that if it's smaller, then we add it to the left  and if it's larger, we add it to the right. If a number already has an occupant where we want  to put it then we simply go down that path and try again. This simple set of rules causes a tree  structure to emerge hence the name. This doesn't have to be applied to numbers either, we could  also apply this to triangles in a mesh as well.

[00:06:10]Binary trees work as long as you have two mutually  exclusive outcomes, like more than or less than, or smaller or bigger, or writing a joke yourself  or relying on Chat-GPT. For triangles in a mesh we can take a certain triangles plane and test  if another triangle is in front of that plane, or behind it. Then like before, we can each [Burp]  entry in the data set and add it to the tree this will generate the same tree structure we saw  with the numbers although admittedly this one happens to be a bit imbalanced. Some of you may  have already noticed the issue with this. For those of you who didn't, when I said a triangle  can either be in front of or behind another, I was lying. What happens if a triangle happens to  be on both sides of another? It turns out there's actually five different outcomes here. Luckily  for us, we can actually narrow this down to the original two again with some special routines for  these extra three cases. If a triangle happens to be exactly in line with another, then they can be  treated as equal. We don't even need to add these to the tree since its plane is already being  represented. If one of the triangle corners happens to be perfectly on the plane of another,  then we use the other triangle plane to split it into two. These two sub-triangles can then be  dealt with independently and added back to the binary tree normally. The last case is the most  complex, but unfortunately also the most common.

[00:07:28]If the triangle happens to be on both sides of  the other's plane and isn't a perfect split, then three sub triangles are going to be created.  This particular mathematical problem happened to be the exact cause of most of my pain implementing  this. I'll spare you the details but basically, two sub triangles will be on one side one, will  be on the other, and you spam dot products to figure out which is the case. Alright this  extra bit of functionality we've added will deal with these three special cases and reduce the  actual results down to in front, or behind again, making fully compatible with the binary tree  once more. For each mesh that we want to use, we can simply generate a binary tree for it once  and keep it forever. We can now return to our original problem of testing if a point is inside  a mesh. For each point, we start at the top of the tree and work our way down by testing if the  point is in front, or behind of the triangle we are at. Once we arrive at the end of the branch we  can perform one last test; if our point is behind the triangle, then we know it's inside the mesh if  it's in front, then we know it's outside the mesh.

[00:08:29]This test will guarantee that any new particles  will be inside the mesh. The last thing we are going to do is connect these particles together.  There are many ways to do this, but I'm simply going to go with a proximity based approach. If  any two particles are close enough then a spring joint will attach them together. To me, this seems  like the most natural and elegant approach to this problem. You do have to figure out the right  distance to use, but this ultimately allows you to customize the soft body further so I view that  as a good thing. So now we've arrived at something good. We can now take basically any mesh we like  and turn it into a soft body. We could improve this by pre-processing the mesh, or simulating  springs on the GPU, but I think this is a good solution for now. To end this video, I'm going  to show you a few ways this could be applied: The first is the most obvious: squishy objects.  This could be a bouncy cube, or a plate of jelly, or the letter T or even a gummy bear. We could  also attach two stress balls to this wall if we wanted to. Here's another use for soft bodies:  cloths. These are quite popular in lots of kitchens today, and they can be used to simulate  capes, clothes, or with a little bit of Ingenuity a flag blowing in the wind, which if you do make I  know you're doing it for a golf game I mean let's be honest this is like 99% of the reason game devs  make flags. There are even more creative ways you can use soft bodies. For example, you could  dynamically adjust the characteristics of the spring joints to create all kinds of effects. You  can make things go stiff, or go soft... if you're a man there's a one in five chance you've already  seen this before. You could even use this Idea to create a balloon that inflates, or an inflatable  mascot or with a little bit more ingenuity, one of these things... what are these  called? Like seriously what the actual f*ck is the name for these? Because we all know  what this is, we've all seen this before, but no one has ever named one apparently. All  right I just googled it and apparently the term is air-dancer so there you go. Now, soft bodies  are cool and all that but unfortunately they're just virtual toys. If you would like to play  with real soft bodies, then be sure to check out my brand new merch in the description.  If you don't like the sound of that, then I actually made a website where you can send me  complaints, the website is patreon.com/b2studios Have a look, and i'll be sure  to respond to your complaints.
