nf-core/mag pipeline: Metagenome Assembly and Binning

[00:00:02]Hello, everyone, and welcome  to this week's bytesize talk.

[00:00:06]I'm happy to present to you today Sabrina  Krakau. She is situated at QBiC at the University of Tübingen. She is talking today  about the nf-core pipeline mag and off to you.

[00:00:22]Thanks Franziska for this kind introduction.  I'm very happy that it finally works out to also present the nf-core/mag pipeline to all of you.  This pipeline you can use for metagenome hybrid assembly and binning. The goal of this pipeline  is to analyze microbial communities by recovering individual genomes. This might be, for example,  particularly useful if you do not have a complete set or high quality reference genomes given.  Such microbial communities could be everything, for example, environmental samples, but also host  associated communities such as the gut microbiome.

[00:01:05]The microbiome samples can be processed  with metagenome shotgun sequencing, which generates short reads. The nf-core/mag  pipeline then essentially combines these reads and assembles them to larger contigs. In a  downstream genome binning step, it bins these contigs to so-called metagenome assembled  genomes, also called MAGs. These MAGs can then further be annotated and also taxonomically  classified. That's the concept of the nf-core/mag pipeline. As for many nf-core pipelines, the  development of this was a quite large community effort with many different contributors,  so just mentioning the main important ones.

[00:01:52]It was started by Hadrien Gourlé, then Daniel  Straub contributed a lot since early on, then I joined, and also since last year, James Yellows  Yates is a main contributor of this pipeline.

[00:02:05]Now I would like to mention the key features of  this pipeline. It can perform a hybrid assembly using both short Illumina and long nanopore  reads. This is useful because if you have assemblies generated only from short reads,  they are often highly fragmented. By using additionally longer reads, this can improve  the contiguity of such resulting assemblies.

[00:02:30]The pipeline also performs a genome binning step  and optionally also a binning refinement step, then can taxonomically classify the resulting bins  and also provides a comprehensive QC statistics.

[00:02:44]Furthermore, it can utilize sample-wise group  information. This can be used for the co-assembly.

[00:02:50]This is important if you have data sets where  you know that certain strains are present across multiple samples, such as within longitudinal  data sets. Because the co-assembly can improve or increase the sequencing depth, this also  allows to recover more lower abundant genomes.

[00:03:10]Additionally, the group information is also  used for the computation of co-abundances, which is used in the genome binning  step. Furthermore, the pipeline also allows the handling of ancient DNA, because it's  containing ancient DNA validation sub-workflow, which is rather specific for this pipeline.  A previous version of this pipeline was already published at the beginning of this  year in NAR Genomics and Bioinformatics, so if someone's interested in more details, you  can also have a look at this application note.

[00:03:46]Here you can see an overview of the pipeline.  The pipeline starts with different pre-processing steps and QC, then the actual assembly is  performed with a final genome binning step. Here in green you can see the processes or different  tools that are run by default by this pipeline.

[00:04:08]In the following I would like to guide  you through the different steps of this pipeline in more detail. Just first, how  can we actually run it? So here you can see an example of the Nextflow command  that is typically used and in order to run it with default settings, just  provide a sample sheet as input file.

[00:04:27]Here you can see an example how the sample sheet  looks like for this pipeline: it contains five columns. The first column contains a sample  name, the second column contains a group name, in this case all samples belong to the same group.  Then you have to provide the path to the input read files, either only to the short reads or  to the short and long reads, so the long reads are optional. Starting with this sample sheet  file now, or if you have only short reads you can also just provide a fastq file directly, the  pipeline then pre-processes the short and long reads separately from each other with different  pre-processing steps. I do not want to discuss them in detail. Maybe just mention that the host  reads can also be removed by mapping the reads to given reference sequences. This information  is also used indirectly for the long reads, since the long reads are filtered based  on the already filtered short reads.

[00:05:30]The short reads can then further be  taxonomically classified already. This can serve for example as a quality control in  order to check for potential contaminations.

[00:05:43]After these pre-processing steps then the actual  assembly is done. This can be done sample-wise or the group information can be used in order to  run a co-assembly, however by default this is done for each sample individually. By default  the tools SPAdes and MEGAHIT are run both.

[00:06:03]However, you should keep in mind that if you  have long reads given and you are interested in the hybrid assembly then only the tool  SPAdes can be used for this. Then the tool QUAST is used in order to assess the quality of  the resulting assemblies and also the assemblies are further processed with the tool PRODIGAL  which predicts protein coding genes for this.

[00:06:27]6:26 That's the assembly part and the contigs of  these assemblies are then further processed in the genome binning step, where the tools MetaBAT2  and MaxBin2 are used, which now bin the contigs to retrieve the actual genomes. The results of  these tools can also additionally be combined in a binning refinement step, which makes use of  DAS Tool. The quality of these bins is as well assessed with the tool QUAST and in addition the  tool BUSCO is used which makes use of single copy orthologs in order to estimate the contamination  or the completeness of the retrieved genomes.

[00:07:10]Additionally the pipeline also uses a custom  script, which estimates the abundance of the individual bins, because it's also a  relatively important output of this pipeline.

[00:07:23]In further downstream processes then the  bins are further taxonomically classified by default using the tool GTDB-Tk, and  also annotated with the tool PROKKA.

[00:07:34]Finally a multiQC report is generated and also  a relatively comprehensive MAG summary report.

[00:07:43]How does the output of the pipeline look  like? Besides all the individual results part of the individual tools, the pipeline  generates a clustered heat map showing the MAG abundances across different samples. Here  you can see an example how this looks like.

[00:07:59]If you would see here, for example, that certain  samples cluster together for which you know that they are originating from different groups this  might indicate that something has gone wrong.

[00:08:11]The pipeline also outputs the MAG summary,  which I already mentioned. This contains for each bin or each MAG, the abundance information  across different samples, the QC metrics from the BUSCO results and the QUAST results, and also  taxonomic classifications from the tool GTDB-Tk.

[00:08:35]And with this, I've shown you the rough  overview of the pipeline and next I would like to show you the impact different assembly  settings can have. For this I simulated some mouse gut data set in the past with the tool  CAMISIM. I generated hybrid data containing Illumina data and Nanopore reads and generated  two groups, each with a time series of four samples. This might be the ideal case where  a co-assembly might be useful. Now I would like to show you some of the resulting  assembly metrics that are commonly used.

[00:09:15]Here you can see, for example, the total  length of the resulting assemblies compared for different pipeline runs for which  different assembly settings were used. The lower two pipeline settings correspond to a  sample-wise assembly and using either only short or short and long reads, so hybrid data, and the  upper two settings correspond to a co-assembly, again with short or short and long reads. And  what we can see is that the total length of the resulting assemblies significantly increased both  by using the hybrid setting, and by applying the co-assembly setting. Similar results we also see  when looking at the number of MAGs, so the number of genomes that could be retrieved from this  data, and also when looking at the N50 values.

[00:10:08]This indicates that the actual setting  that is used for the assembly within this pipeline can have a relatively huge impact  on the results. It's definitely good that the pipeline provides different settings,  so that you can really choose the correct setting for your input data, and it might  also be worth to compare different settings.

[00:10:34]Another topic I would like to shortly mention  is the resource requirements, because this came up quite often in the Slack channel, and  it's also somehow difficult to estimate in advance, because it really differs depending  on the input data. The main requirements are both for memory and time, coming from the assembly  step. As I mentioned already it really differs for different input data sets and I collected  some numbers just to give you a rough idea for different pipeline runs that were run  by Daniel Straub on our compute cluster.

[00:11:11]For one rather small sample, which was a culture  sample, both MegaHIT and SPAdes required less than 25 GB and were finished in a couple of hours.  However, for a larger river sample data set, MegaHIT took already more than 100 GB of  RAM, and it took more than one day to finish, and SPAdes even took more than 900 GB of  memory, and it required more than nine days.

[00:11:38]There was another very large data set  containing 15 soil samples for which also a co-assembly was performed and for this  MegaHIT required one TB and more than 17 days, and SPAdes could not even be run because it  would have required more than two TB of memory.

[00:11:55]This just shows that even for smaller data  sets, you cannot run this on your laptop.

[00:12:01]In general, one can say that it depends on  the sequencing depths, the number of samples, the complexity of the underlying metagenome,  and also on the applied tool and setting.

[00:12:12]For this it might be worth noting  that both assembly tools are run by default but MegaHIT requires much fewer  resources than SPAdes, and if you do not want to compute a hybrid assembly it might make  sense to consider the --skip_spades parameter.

[00:12:29]Additionally, the co-assembly also increases  the required resources because it pools samples. At least for one individual task,  the required memory and time is much higher.

[00:12:40]This is something important to keep in mind,  because also if you want to run it on larger data sets, you might want to provide a custom  config file in order to adjust the resources required for your particular data set. With this we have seen how we can run the nf-core/mag pipeline for modern metagenomic data  sets. As I mentioned already at the beginning, it can also handle ancient DNA. For this James  and Maxime added an ancient DNA validation sub-workflow. This is particularly interesting  because, as far as we know at least, there's no other such pipeline which can handle ancient DNA.  What this essentially does is that it performs identification of possible ancient contigs by  modeling ancient DNA damage patterns, and then polishes the contigs in order to remove the errors  that are caused by the presence of such ancient DNA damages in order to allow more unimpaired  downstream analyses. This might be interesting for some of you to know that this pipeline can  also handle ancient metagenomic data analysis.

[00:13:53]With this, I'm already at the end of my  presentation, just a few words on the outlook. The next release James already prepared,  it just requires one more review. It contains another optional binning tool, namely CONCOCT.  It will also allow optionally the bin QC with CheckM and GUNC. For the midterm future, it would  be also very nice if a functional annotation step could be added, so depending on the strategy,  either for example using HUMAnN 3 or eggNOG, and also a standalone long read assembly option  would be very nice by using, for example, the tool meta-flye, such that the pipeline  could be also run without short read data.

[00:14:41]In general, if you are interested in contributing,  or if you have any questions or problems you would like to discuss, you can join us in the nf-core  Slack channel dedicated to the MAG pipeline, or have a look at our GitHub repository. We're  always happy about feedback or particular bug reports and issues. With this, I would  like to thank you for your attention.

[00:15:05]Then, in particular, my colleagues from QBiC,  importantly Daniel Straub for many contributions, James and Maxime from the MPI for Evolutionary  Anthropology, Hadrien, of course, and importantly, the whole nf-core core team and community for  helping with the development, for reviewing, testing and creating issues. With  this, I'm happy to take any questions.

[00:15:30](host) Thank you very much. There is  indeed one question already in the chat.

[00:15:37](question) It was at the very beginning  when you were talking about examples, and you mentioned CAMISIM. Could you  explain more in detail what this is?

[00:15:49](answer) This is a tool which was also used in  the CAMI challenge to simulate metagenomics data.

[00:15:58]It's using as input different genome sources. I  used in this case a set of mouse genome sources, which was given from some mouse gut data  sets. Then it can simulate Illumina and nanopore data and simulate also different  taxonomic profiles. But the more details, I would also have to look up, it was quite a while  ago. Was there any particular question about this?

[00:16:30](question cont.) No, it was just a question, "what  is CAMISIM?", but I think James has now added some links to articles. If anyone is  interested, they can have a look at that.

[00:16:45](host) For anyone else, if there are more  questions, you can now unmute yourself and just ask them straight away. Or you can put them  in the chat and I will read them out for you.

[00:17:01](question) I would actually have a question.

[00:17:04]What happens to multi-mappers? I  can imagine that if you have related bacteria that it would also map to different  ones. How does the pipeline deal with that?

[00:17:15](speaker) I mean, this is handled  by the assembly tools then somehow.

[00:17:23](question cont.) But are they removed  or added to all of them? Any idea?

[00:17:29](speaker) Someone of the others are more in the details  of this algorithmic parts of the assembler.

[00:17:40](audience) Do you mean when you're mapping back  to the contigs or during the assembly itself?

[00:17:44](question cont.) During the assembly. I  mean, you map to the genomes, I guess?

[00:17:49](audience cont.) No. We need to explain  the main concept there. But there's some fancy maths magic that goes on which  estimates which reads most likely go with each other based on the number  of mutations they have with each other.

[00:18:07]There's some weird maths stuff which  works out which is the best grouping.

[00:18:12](question cont.) Okay, then I  misunderstood that part. Thank you.

[00:18:17](host) Are there any more  questions from the audience?

[00:18:24]It doesn't seem so. If you have any more  questions later on, as you mentioned, you can always go to nf-core Slack and ask  questions there. If this is now all the questions answered so far, I would like to thank  Sabrina again for this very nice talk. Of course, as usual, I would also like to thank the  Chan Zuckerberg Initiative for funding the bytesize talks and of course everyone in the  audience for listening. Thank you very much.

[00:18:53](speaker) Thanks.
