DNS Resolver (Sockets, Packets & Python)

Learning Goal: Develop a custom DNS resolver from scratch to master low-level network socket programming, bitwise operations, and binary packet parsing using Python. By the end of this curriculum, you will understand how DNS queries are structured, transported over UDP, parsed byte-by-byte according to RFC 1035, and recursively resolved.

Prerequisites

Intermediate Python programming skills (functions, classes, basic exception handling).
Basic familiarity with command-line interfaces (terminal/command prompt).

Estimated Study Time

15 Hours (including video lectures, reading RFC documentation, and hands-on coding).

Module 1: Network Basics & The Domain Name System

This module covers the core concepts of computer networks. You will explore how machines locate each other using IP addresses, the functional trade-offs between the TCP and UDP transport protocols, and how the Domain Name System (DNS) operates as the distributed telephone directory of the internet.

Knowledge Checkpoint

What is the difference between a recursive DNS resolver and an authoritative DNS name server?
Why does standard DNS primarily use UDP port 53 instead of TCP?
What is the structural difference in address space between IPv4 (32-bit) and IPv6 (128-bit)?
What happens when a DNS query packet is lost in transport over UDP?

Module 2: Network Socket Programming with Python

This module transitions from theory to execution. You will learn to use Python's built-in socket module to create a low-level UDP server and client. You will learn how to bind sockets to ports, listen for inbound datagrams, parse the sender's metadata, and return network responses.

Knowledge Checkpoint

What parameter flags must be passed to socket.socket() to instantiate a UDP socket instead of a TCP socket in Python?
What is the purpose of the bind() method in a network socket server?
Why does recvfrom(1024) return a tuple instead of just a raw byte array?
How do you convert a Python string to a raw byte array before transmitting it over a socket, and vice versa?

Module 3: Binary Representation and Python's Struct Module

To parse and construct network packets, you must be able to read and write raw binary configurations. This module focuses on binary, hexadecimal, bitwise operators, and Python's built-in struct module, which maps binary buffers to Python data types.

Curriculum Gap Alert: The video pool lacks a dedicated, comprehensive tutorial on using the Python struct module specifically for DNS parsing. To address this, study the recommended real-world video below on medical packet parsing, and thoroughly read the structured walk-through provided in the section below.

Python `struct` and Bitwise Operations Reference Guide

Since DNS uses big-endian byte order (also known as Network Byte Order), you must prefix format strings with > when packing or unpacking.

import struct

Parsing a 12-byte standard DNS Header

Format: 6 unsigned short integers (16-bit each -> 2 bytes * 6 = 12 bytes)

'>' specifies big-endian network byte order. 'H' specifies a 16-bit unsigned short.

dns_header_format = ">HHHHHH"

raw_bytes = b'\xaa\xbb\x01\x00\x00\x01\x00\x00\x00\x00\x00\x00' tx_id, flags, q_count, ans_count, auth_count, add_count = struct.unpack(dns_header_format, raw_bytes)

print(f"Transaction ID: {hex(tx_id)}") # Output: 0xaabb print(f"Flags Field: {bin(flags)}") # Output: 0b100000000

Parsing Sub-byte Flags

In the 16-bit DNS flags field:

QR (Query/Response) is 1 bit at position 15 (most significant bit).
Opcode is 4 bits at positions 11–14.
AA (Authoritative Answer) is 1 bit at position 10.
TC (TrunCation) is 1 bit at position 9.
RD (Recursion Desired) is 1 bit at position 8.
RCODE (Response Code) is 4 bits at positions 0–3.

To extract these in Python, use bitwise shifting and logical masking:

To read Recursion Desired (RD) - Bit 8

rd = (flags >> 8) & 1

To read Response Code (RCODE) - Bits 0-3

rcode = flags & 0x000F

Knowledge Checkpoint

What does > represent in a Python struct format string, and why is it essential for network applications?
How many bytes of data are represented by the format string >HHI?
Write a Python expression using bitwise operators to check if the most significant bit (bit 15) of a 16-bit flag integer is set to 1.
How do you convert the decimal value 254 into hex, binary, and a raw byte representation in Python?

Module 4: DNS Packet Structure & RFC Spec

This module covers the layout of a DNS packet as specified in RFC 1035. You will analyze how queries are constructed under the hood, parsing headers, questions, answers, authority zones, and additional records.

Curriculum Gap Alert: Standard tutorials online often rely on high-level libraries (like dnspython or scapy) or Wireshark captures. To build a resolver from scratch, you must understand the exact wire format. Study the videos below to understand the physical layer capture, and use the detailed breakdown below to map these layouts directly to code.

The DNS Packet Wire Format (RFC 1035)

Every standard DNS packet (both request and response) has a fixed 12-byte header, followed by variable-length payload fields.

+---------------------------------------------------+ | Header (Fixed 12 Bytes) | +---------------------------------------------------+ | Question Section (Variable Length) | +---------------------------------------------------+ | Answer Section (Variable Length) | +---------------------------------------------------+ | Authority Section (Variable Length) | +---------------------------------------------------+ | Additional Section (Variable Length) | +---------------------------------------------------+

Detailed Header Layout

The Question Section

The Question Section format is:

QNAME: A variable-length field that encodes domain names as a sequence of "labels". For example, google.com is encoded as: \x06g o o g l e \x03c o m \x00 (length-prefixed strings ending with a null byte 0x00).
QTYPE: A 2-byte integer specifying the query type (e.g., Type A = 0x0001).
QCLASS: A 2-byte integer specifying class (usually Internet, IN = 0x0001).

Parsing DNS Name Pointers (Compression)

To reduce packet size, DNS responses often use compression pointers. If the first two bits of a length byte are 11 (binary), it indicates a pointer.

+--+--+--+--+--+--+--+--+--+--+--+--+--+--+--+--+ | 1 1| OFFSET | +--+--+--+--+--+--+--+--+--+--+--+--+--+--+--+--+

If you encounter 0xC00C (which is 11000000 00001100 in binary), you strip the first two bits (0xC000) to find the remaining value of 12. This means you should jump to offset 12 in the raw packet to read the domain name.

Knowledge Checkpoint

Draw the layout of a DNS packet header and list the size of each field in bits.
How is the domain name mail.yahoo.com formatted in a raw DNS question payload? (Write out the hexadecimal bytes).
What is the purpose of the compression schema in DNS, and how do you identify a compressed pointer byte?
What integer code represents a standard IPv4 host address lookup (A record) in the QTYPE field?

Module 5: Building a Custom DNS Resolver from Scratch

In this module, you will write a fully functional custom DNS recursive resolver in Python from scratch. Your program will listen on a UDP port for incoming client queries, parse the domains, resolve them recursively by querying official DNS root servers, extract the answers, and compile a binary response payload back to the client.

Curriculum Gap Alert: Most videos on building a DNS server in Python focus on installing or configuring third-party products (like Pi-hole, pfSense, or BIND9). To help you build a programmatic resolver from scratch, use the guides below alongside the coding fundamentals videos.

Step-by-Step Code Architecture Guide

Your custom DNS resolver should follow this architecture:

              +-----------------------------------+
              |      1. Listen on Port 5353       |
              |         (Python UDP Socket)       |
              +-----------------+-----------------+
                                |
                                v (Inbound Client Query)
              +-----------------+-----------------+
              |      2. Parse Binary Header       |
              |        (Extract Query Domain)     |
              +-----------------+-----------------+
                                |
                                v
              +-----------------+-----------------+
              |      3. Recursive Resolve Loop    |
              |  Query Root Name Server (198.41.0.4)|
              +-----------------+-----------------+
                                |
        +-----------------------+-----------------------+
        |                       |                       |
        v (Recv CNAME/NS Record)|                       v (Recv IP Address)

+-----------+-----------+ | +-----------+-----------+ | Query Name Server IP | | | Return Final Answer | | returned in Authority | | +-----------------------+ +-----------+-----------+ | ^ | | | +-----------------------+

Core Classes to Implement

To organize your code, implement these class structures in your resolver script:

class DNSHeader: def init(self, tx_id, flags, num_questions, num_answers, num_authorities, num_additionals): self.tx_id = tx_id self.flags = flags self.num_questions = num_questions self.num_answers = num_answers self.num_authorities = num_authorities self.num_additionals = num_additionals

@classmethod
def parse(cls, data):
    # Unpacks 12 bytes using struct
    pass

def to_bytes(self):
    # Pack fields into 12 big-endian bytes
    pass

class DNSQuestion: def init(self, name, qtype, qclass): self.name = name self.qtype = qtype self.qclass = qclass

@classmethod
def parse(cls, data, offset):
    # Parses the name and unpacks QTYPE and QCLASS
    pass

class DNSRecord: def init(self, name, rtype, rclass, ttl, rdata): self.name = name self.rtype = rtype self.rclass = rclass self.ttl = ttl self.rdata = rdata # IP Address bytes or authoritative Domain bytes

The Resolution Loop Engine

To resolve a query from scratch:

Extract the requested domain name from the inbound client request (e.g., example.com).
Query a Root Name Server (such as Verisign's standard root server 198.41.0.4) on Port 53 with your structured query bytes.
Parse the response. Look at the Answers count. If it contains an "A" record matching your domain, return it.
If there is no answer but you receive Authority Records (NS name servers) and Additional Records (IP addresses of those name servers), extract those IP addresses.
Re-run your query step using one of those newly parsed authoritative IP addresses (this resolves the TLD and domain authoritative level).
Loop recursively until you receive an IP answer, then send this result back to the original client.

Knowledge Checkpoint

Implement the DNSQuestion.parse method in Python to successfully extract a query domain name, resolving any pointers.
Write a function that takes a query domain name string and returns the raw bytes formatted as length-prefixed labels ending in a null byte.
Build a functional recursive resolver routing query requests from root IP 198.41.0.4 down to authoritative servers.
Test your resolver locally using the command-line tool: dig @127.0.0.1 -p 5353 example.com. Verify that the correct IP address is returned.

Course Map

Key People Index

Computerphile (@Computerphile): A popular computer science educational channel. Known for breaking down complex systems like routing tables and protocol designs into accessible concepts.
NeuralNine: A software developer and educator specializing in low-level socket abstractions, multi-threading architectures, and secure client-server design.
PieterExplainsTech: A hardware and networking systems engineer known for clear technical comparisons of transport architectures.

Final Self-Assessment

Complete this comprehensive self-assessment to verify that you have mastered this curriculum:
